The IBASE Technology MBB1002 eATX motherboard is equipped with AMD EPYC Embedded 8004 series processors, supporting up to 576GB DDR5-4800 ECC memory, tailored for advanced edge AI and data-heavy applications in various sectors like manufacturing, transportation, and edge computing infrastructure.
This embedded motherboard provides five PCIe Gen5 x16 slots for GPU and AI accelerator integration, dual 10GbE networking, NVMe and SATA storage, and USB 3.2 ports with PDPC.
Key specifications of the IBASE MBB1002 include:
- SoC: AMD EPYC Embedded 8004 processor, supporting up to 64 Zen4 cores (128 threads) via the AMD SP6 LGA 4844 socket
- System Memory: Up to 576GB DDR5-4800 with ECC using 6 RDIMM slots
- Storage:
- 4 SATA III ports
- NVMe SSD via M.2 Key-M 2280 socket
- NVMe SSDs via 2 MCIO x4 sockets
- Networking: Dual 10GbE RJ45 ports via Intel XC710-AT2
- USB Connectivity:
- 2 USB 3.2 Gen 1 Type-A ports with PDPC
- 2 USB 2.0 via pin header
- Serial: RS232 COM port
- Expansion: 5 PCIe Gen5 x16 slots for enhanced GPU and AI accelerator capability
- Security: TPM 2.0
- Other Features:
- AMI BIOS/UEFI firmware
- Watchdog timer, hardware monitor
- 4 fan headers, SMBus
- LED indicators for power, HDD, and status
- Power Supply:
- 24-pin SSI and 3 8-pin SSI 12V power connectors
- Dimensions: 304 x 244 mm (eATX form factor)
- Operating Temperature: 0°C to 60°C; Storage Temperature: -20°C to 80°C
- Humidity: 0% to 90%, non-condensing at 60°C
