Beelink ME Pro is a small 2-bay hybrid NAS and Windows 11 mini PC based on Intel N95 (Alder Lake-N) or N150 (Twin Lake) SoC, featuring two 3.5-/2.5-inch SATA bays and three M.2 2280 NVMe slots for storage. Its “DIY drawer” design allows motherboard swaps for upgrades.
The unit supports up to 16 GB of LPDDR5 memory, 5 GbE and 2.5 GbE networking, Wi-Fi 6, Bluetooth 5.4, and various I/Os including USB-C (10 Gbps), USB-A, HDMI 2.0, and a 3.5 mm audio jack. An internal blower cooling system, aluminum chassis with thermal pads, and anti-vibration mounts enhance thermals and noise control. It suits home NAS, media server, Proxmox/TrueNAS host, small office file server, lightweight virtualization, backup appliance, and compact desktop PC uses.
Beelink ME Pro specifications:
- SoC Options:
- Intel Processor N95 quad-core “Alder Lake-N” processor @ up to 3.4 GHz (Turbo) with 6MB cache, 16 EU Intel UHD graphics @ 1200 MHz; TDP: 15W (tuned to 25W max in BIOS)
- Intel Processor N150 quad-core “Twin Lake” processor @ up to 3.6 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics @ 1000 MHz; TDP: 6W (tuned to 25W max in BIOS)
- Memory – 12GB or 16GB LPDDR5 4800MHz (soldered)
- Storage
- 2× SATA bays for 2.5-inch / 3.5-inch HDDs (up to 30 TB per drive, 60 TB total)
- 1× M.2 2280 PCIe 3.0 x2 NVMe slot (up to 4 TB)
- 2× M.2 2280 PCIe 3.0 x1 NVMe slots (up to 4 TB each)
- Up to 72 TB total storage (depending on configuration)
- Video Output
- HDMI 2.1 up to 4K @ 60Hz
- DisplayPort Alt Mode via USB-C port
- Audio – 3.5mm headphone/mic jack
- Networking
- 5GbE RJ45 jack via Realtek RTL8126 controller
- 2.5GbE RJ45 jack via Intel i226-V controller
- Wi-Fi 6 and Bluetooth 5.4
- Supports link aggregation, virtualization, and software routing
- USB
- 1x USB 3.2 Gen 2 (10Gbps) Type-C port
- 1x USB 3.2 Gen 2 (10Gbps) Type-A port
- 2x USB 2.0 Type-A ports
- Misc
- Power button
- Reset and CLR CMOS pinhole buttons
- Internal blower fan with high static pressure
- Dual-sided silicone anti-vibration dampeners for HDDs
- Tool-less slide-out motherboard for dust cleaning and maintenance
- Compatible with Intel, AMD, and Arm platforms (future upgrades)
- Power Supply – 19V / 6.32A (120W) DC jack
- Dimensions – 166 × 121
