The AAEON NIKY-2215-NX is a 21.5-inch Full HD AI Touch Panel PC utilizing the NVIDIA Jetson Orin NX 8GB/16GB, tailored for AI-driven HMI applications like production line inspection and industrial monitoring systems.
This panel PC comes with dual GbE RJ45 jacks, four USB 3.2 Type-A ports, CAN Bus, RS-232/422/485, and DIO DB-9/15 connectors, alongside three M.2 slots for NVMe storage, WiFi/Bluetooth, and 4G LTE/5G cellular connections. It functions between -5°C and +55°C, withstands vibration and shock, and accepts a 12V to 24V DC input.
AAEON NIKY-2215-NX specifications:
- SoM – NVIDIA Jetson Orin NX
- Jetson Orin NX 16GB – 8-core Arm Cortex-A78AE CPU, 1024-core NVIDIA Ampere GPU, up to 157 TOPS, 16GB LPDDR5
- Jetson Orin NX 8GB – 6-core Arm Cortex-A78AE CPU, 1024-core NVIDIA Ampere GPU, up to 117 TOPS, 8GB LPDDR5
- Storage – 128 MB (default) NVMe SSD via M.2 2280 M-Key socket
- Panel
- Display Type – 21.5-inch TFT-LCD
- Resolution – 1920 (H) x 1080 (V)
- Max. Colors – 16.7M
- Luminance – 350 cd/m² (Typ.)
- Viewing Angle – 178° (H) ; 178° (V)
- Projected capacitive multi-touch; light transmission >= 85%
- Back Light LED
- Back Light MTBF – 30,000 hours
- Networking
- 2x Gigabit Ethernet RJ45 ports
- WiFi and Bluetooth via M.2 2230 E-Key socket
- 4G LTE/5G cellular via M.2 3042/3052 B-Key socket
- 6x antenna holes
- USB
- 4x USB 3.2 Gen 2 Type-A ports
- 1x Micro USB port for OS Flash
- Serial
- RS-232/422/485 via DB-9 connector
- CAN Bus via DB-9 connector
- Expansion
- M.2 2280 M-Key PCIe socket for NVMe SSD
- M.2 2230 E-Key socket
- M.2 2042/3052 B-key socket
- 8-bit GPIO via DB-15 connector
- Misc
- Power ON/OFF switch
- Recovery pinhole
- Mounting – VESA 100 / Panel Mount
- Power Supply – 12~24V DC via 2-pin screwable terminal
- Dimensions – 516.4 x 316.0 x 69.6 mm
- Weight (Gross) – 8.02 kg
- Construction – Aluminum Front Bezel + Metal Chassis
- Temperature Range – Operating: -5°C ~ 55°C, with 0.7 m/s airflow; storage: -20°C ~ 60°C
- Humidity – Storage: 90% @40°C, non-condensing
- Vibration – 1Grms / 5~ 500Hz / operation
- SHOCK – 15 G peak acceleration (11 msec. duration)
- EMC – CE/FCC Class A
The system operates on Ubuntu 22.04 with NVIDIA JetPack. It
