The Beelink EX Mate Pro is a versatile USB4 v2 (80 Gbps) dock equipped with four PCIe Gen4 slots for M.2 SSDs. It includes a 140W charger providing 96W USB PD charging for laptops or mini PCs, 2.5GbE networking, HDMI and USB4 video outputs, and an integrated quad-microphone array and speaker for voice functionality.
Additional features consist of a 15W PD USB4 v2 port for peripherals like an external GPU or display, Bluetooth for wireless speaker conversion, USB 3.0 and USB 2.0 host ports, and control buttons for volume and microphone mute.
Specifications of the Beelink EX Mate Pro include:
– Storage: 4x M.2 PCIe Gen4 x1 slots for NVMe SSDs
– Video Output: HDMI port up to 4Kp60, USB4 v2 port with support for two independent displays
– Audio: Integrated speaker, quad-mic array with a 5-meter range connected to a B1 AI noise-cancellation chip, Bluetooth speaker capability
– USB: USB4 v2 (80 Gbps) port with 96W PD for host connection; USB4 v2 (80 Gbps) port with 15W PD for peripherals; USB 3.0 and USB 2.0 Type-A ports
– Misc: Power button, LED indicators for power, Bluetooth, microphone, and touch controls on top with various function buttons, includes a silent fan
– Power Supply: 140W built-in power supply with 110V/230V AC input, 96W power delivery for laptops, 15W for peripherals
– Dimensions: 99 x 99 x 98.3 mm
The Mate Pro comes with a storage bag, user manual, power cord, “80Gbps dual USB-C cable,” and an HDMI cable. It has no specific software and functions with existing applications on your device due to its standard USB4 v2 interface.
Beelink offers the “EX Mate Pro All-In-One Docking Station” for $199 plus shipping. It is expected to be available on the company’s Amazon and AliExpress stores.
