Boardcon Tiny1126B reduces the size of the company’s MINI1126B-P Rockchip RV1126B system-on-module (SoM) from 38x30mm to 34x30mm, aiming for even more compact AI vision systems such as smart cameras, smart door locks, inspection cameras, robotics for cleaning and logistics, DMS (Driver Monitoring Systems), BSD (Blind Spot Detection) solutions, and smart displays.
Despite its smaller form, the Tiny1126B includes two 0.4mm pitch 100-pin connectors, upgrading from two 0.5mm pitch 80-pin connectors found in its predecessors, with more I/Os. It notably adds a USB 3.0 DRD (Dual-Role Device) interface, an additional SDMMC interface, more SPI and I2C interfaces, Fast Ethernet, among others. Other specifications, such as memory capacity (up to 4GB LPDDR5) and storage (up to 256GB eMMC flash), stay unchanged.
Boardcon Tiny1126B system-on-module
Boardcon Tiny1126B specifications:
- SoC – Rockchip RV1126B
- CPU – Quad-core Arm Cortex-A53 up to 1.6 GHz with 32KB L1 I-Cache and 32KB L1 D-Cache, unified 512KB L2 Cache
- GPU – 2D Graphics Engine
- VPU
- Video Decoder – H.265/H.264 up to 3840×2160 @ 30fps
- Video Encoder – H.265, H.264, JPEG up to 12Mbps @ 30fps
- JPEG Decoder
- AI accelerator – Rockchip NPU engine up to 3 TOPS (INT8); supports INT4, INT8, INT16, and FP16 models; TensorFlow, ONNX, PyTorch, and Caffe frameworks.
- System Memory – 2GB or 4GB LPDDR4
- Storage – 8GB, 16GB, 32GB, 64GB, 128GB, or 256GB eMMC flash
- Networking chip –
Realtek RTL8211F-CG GbE PHY(moved to carrier board if needed) - 2x 100-pin, 0
